· Ultra thick ceramic plunger, has s better durability
· Double gasket sealing system
· Double port oil seal
· The increasing size of the connecting rod is made if alloy with low friction coefficient
· Unique extension of space, the use of lower temperature, more durable life
| Model | Pressure (bar) | Flow Rate (L/min) | Speed (rpm) | Power (kW) | Pisotn dia (mm) | Shaft dia (mm) | Weight (kgs) | Carton Dimension (mm) |
| 3WZ-1806B1 | 150 | 14 | 3400 | 6.5HP | 18 | 19.05 | 8 | 320×250×240 |
| 3WZ-1806B2 | 150 | 14 | 3400 | 6.5HP | 18 | 20 | 8 | 320×250×240 |
| 3WZ-1807C | 100 | 9 | 1450 | 1.8 | 18 | 24 | 10 | 320×250×240 |
| 3WZ-1810C | 120 | 12 | 1450 | 2.2 | 18 | 28/24 | 10 | 320×250×240 |
| 3WZ-1812C | 100 | 14 | 1450 | 2.2 | 18 | 28/24 | 10 | 320×250×240 |
| 3WZ-1812C | 150 | 14 | 1450 | 3 | 18 | 28/24 | 10 | 320×250×240 |
| 3WZ-1812C | 200 | 14 | 1450 | 4 | 18 | 28/24 | 10 | 320×250×240 |
| 3WZ-1812C | 260 | 14 | 1450 | 5.5 | 18 | 28/24 | 10 | 320×250×240 |
| 3WZ-1814C | 260 | 16 | 1450 | 7.5 | 18 | 28/24 | 10 | 320×250×240 |
| 3WZ-1814C | 300 | 16 | 1450 | 9.5 | 18 | 28/24 | 10 | 320×250×240 |
1.Pump body with rough line stripes
2.Top quality, large size needle roller bearings
3.With large cross-section of the large axis, you can better match the torque transmission
4.With a longer cross section of the oversized shaft, you can better fil the torque transmission
5.Inlet and outlet check valve is equpped with alarger flow channel
6.Wroughe copper pump head is more robust
